7.2.14 PCIe Mini Slot (M_PCIE1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 WAKE# 2 VCC3
3 RESERVED 4 GND
5 RESERVED 6 VCC1.5
7 CLKREQ# 8 N/C
9 GND 10 N/C
11 REFCLK0- 12 N/C
13 REFCLK0+ 14 N/C
15 GND 16 N/C
17 N/C 18 GND
19 N/C 20 N/C
21 GND 22 PERST#
23 PERn3 24 VCC3_AUX
25 PERp3 26 GND
27 GND 28 VCC1.5
29 GND 30 SMB_CLK
31 PETn3 32 SMB_DATA
33 PETp3 34 GND
35 GND 36 USB6_DATA-
37 RESERVED 38 USB6_DATA+
39 RESERVED 40 GND
41 RESERVED 42 LED_WWAN#
43 RESERVED 44 LED_WLAN#
45 RESERVED 46 LED_WPAN#
47 RESERVED 48 VCC1.5
49 RESERVED 50 GND
51 RESERVED 52 VCC3
Table 7-15: PCIe Mini Card Slot (M_PCIE1) Pinouts
