AFL-xxA-N26 Series Panel PC
Page 124
7.2.8 HDD LED Connector (HDD_CN1)
7.2.9 I2C Connector (CN4)
7.2.10 LVDS Connector (LVDS1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 LVDSA0+ 4 LVDSA0-
5 LVDSA1+ 6 LVDSA1-
7 LVDSA2+ 8 LVDSA2-
9 LVDSACLK+ 10 LVDSACLK-
11 LVDSA3+ 12 LVDSA3-
13 GND 14 GND
15 NC 16 NC
17 VCCLCD 18 VCCLCD
19 VCCLCD 20 VCCLCD
Table 7-11: LVDS Connector (LVDS1) Pinouts
PIN NO. DESCRIPTION
1 +5V
2 HD_LED
Table 7-9: HDD LED Connector (HDD_CN1) Pinouts
PIN NO. DESCRIPTION
1 GND
2 SMBDATA
3 SMBCLK
4 +5V
Table 7-10: I2C Connector (CN4) Pinouts
