FOLUX LX Series Flat Panel PC
Page 60
4.5.4 JP6: COM2 Mode Select Jumper Settings
The COM2 can be selected as RS-232 or RS-485.
JP6 Description
Short 1-2 RS-232 Default
Short 2-3 RS-485
Short 4-5 RS-232 Default
Short 5-6 RS-485
Short 7-8 RS-232 Default
Short 8-9 RS-485
Short 10-11 RS-232 Default
Short 11-12 RS-485
Table 4-4: COM2 Mode Select Jumper Settings
