FOLUX LX Series Flat Panel PC
Page 12
RF Output Power Class 2 (under 4dBm)
Antenna Terminal 50 Ohms
DC Power DC 3.3V or DC 5V
I/O Interface USB 2.0 interface
Two GPIO Interface LED link indicator interface
Dimensions 35mm x 11mm
Operating System Windows XP, Windows 2000, Windows 98SE, Windows Me
Table 1-6: Bluetooth Module Specifications
1.4.7 Optional GPRS Module Specifications
The GPRS module is one of the OEM options for the AFOLUX LX series. The technical
specifications of the GPRS module are listed in
Table 1-7.
Specification GPRS Module
Quad-band operation GSM850, EGSM 900, DCS 1800, PCS 1900
GSM Power Class 4 (2W) for 850/900 bands
GSM Power Class 1 (1W) for 1800/1900 bands
EDFE class E2 (+27dBm in 850/900 bands,
+26dBm in 1800/1900 bands)
EDG/GPRS/GSM Air Interface
GSM/GPRS Rel ’97; PCS 1900 Rel ’98; EGPRS Rel ’99 compliant
GPRS Class 10, coding schemes 1-4
EDGE Class 10, Multi-slot classes 1-9
GPRS/EGPRS Class B type 1 MT
Link Adaptation
EGPRS/GPRS (PS) Feature Set
Incremental redundancy (IR)
USB Interface USB 2.0 +5VDC
SIM Card Interface 3.0V interface
Temperature -30°C ~ +65°C
Humidity Up to 95%, non-condensing
Dimensions 109.3mm x 42.7mm x 17.7mm
Operating System Windows 2000/XP Home/XP Professional
Table 1-7: GPRS Module Specifications
