FOLUX LX Series Flat Panel PC
Page 8
SPECIFICATION AFL-07A-LX AFL-08A-LX AFL-10A-LX AFL-12A-LX
Resolution 800 x 480 800 x 600 800 x 600 1024 x 768
Brightness 350cd/m
2
220cd/m
2
or
450cd/m
2
400cd/m
2
450cd/m
2
Contrast Ratio 400:1 500:1 500:1 700:1
Viewing Angle (H-V) 140/100 130/110 120/100 160/160
Backlight MTBF 30000 20000 50000 50000
Touch Screen 4-wire resistive type 4-wire resistive type 5-wire resistive type 5-wire resistive type
Extension 1 x Mini PCI (for wireless LAN module)
1 x Bluetooth module (USB interface, Bluetooth v2.0)
Drive Bay N/A N/A N/A
GPRS Module N/A N/A Optional
1 x 2.5” HDD bay or
optional GPRS module
SSD CompactFlash
®
Type II
Audio AMP 1.5W + AMP 1.5W (internal speaker)
I/O 1 x RS-232 serial port
1 x RS-232 or RS-422/485 serial port
2 x 10/100 Mbps Ethernet port
2 x USB 2.0 port
1 x Power switch
1 x Reset button
1 x AT/ATX power switch (internal)
Power 12V, 36W DC power adapter
Power Consumption 20W 20W 25W 29W
Mounting Feature Panel, Rack, Wall, Arm, Stand
Operating
Temperature
0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC ~ 50ºC 0ºC-50ºC
0ºC-40ºC (using HDD)
Relative Humidity 5% ~ 80% RH, non-condensing
Vibration 5 - 17Hz, 0.1” double amplitude displacement.
17 - 640Hz, 1.5G acceleration, peak to peak.
Shock 10G Acceleration, peak to peak (11ms)
Dimension (W x H x
D)
226 x 140 x 41 234 x 184 x 42 276 x 227 x 50.7 304 x 246 x 50
Net/Gross Weight 0.6 Kg 0.8 Kg 1.4kg 1.8 Kg
