Indication・Operation
Power SW
Power ON/OFF
Frequency select SW
Frequency/DFS mode select (5 position)
UNI/MULTI select SW
UNICAST / MULTICAST select
Status LED
MODE STATUS LED : RED・GREEN two color LED ×2
LINK LED : RED・GREEN two color LED ×1
Power
Power input
Battery input: 11-17V / Ext-DC input: 11-17V
Power output
Through-out the DC power (Battery or Ext-DC)
Recommended battery
IDX ENDURA series Lithium Ion battery
In and Out terminal
Video input
BNC ×2 (SD-SDI/HD-SDI・buffered out)
Battery input
V-Mount ×1 (P-V2)
Power out
V-Plate ×1 (A-NH2E equivalent）
Ext-DC input
Canon XLR-4 ×1 (Female, Pin1:minus, Pin4:plus)
Product specification
Dimension
Width 159mm Depth 72mm Height 190mm
(W6.3, D2.8, H7.5 inches)
Weight
800g / 1.8Lb
Power consumption
Max 12W
Operating temperature
0～40℃ (No Dew)
Regulation/Certification
FCC: Part 15 subpart B (class A),
Part 15.407 (Part of 15C),
Part 15 Subpart E
RoHS
