Fig. 5.7 – Triaxial head fixed to the tripod
12. rotate the three axial head, working on the three handles until it perfectly is
levelled with the two spirit levels positioned near the top of the three axial head
(ensure that the handles are well tightened).
13. unblock the hexagonal quick lock from the three axial head by acting on the 2
levers as shown in Fig. 5.8.
Fig. 5.8 – Unblocking the levers of the quick lock mechanism
14. Remove the hexagon from the triaxial head and remove the plastic cap covering
the hexagon screw.
15. Insert the quick lock hexagon screw into the threaded hole on the bottom of the
sensor , working on the metallic nut (Fig. 5.9);
Handle
for
elevation
control
Handle for
azimuth control
Handle for
horizontal
control
