Fig. 5.5 – Composition of the triaxial head
7. Remove the plastic tags from the long handle and the triaxial head.
8. Screw in the two short handles in the yellow coloured nut covers.
9. Screw the long handle into the threaded hole on the side of the triaxial head.
10. Tighten the three handles.
Fig. 5.6 – Mounted triaxial head
11. Screw the triaxial head onto the filleted pin on the top of the tripod;
Adjustment
handles
Hexagonal
lock
Triaxial
head
