4.3 Control and acquisition PC
The IBIS-S system is supplied with a notebook PC, model
PANASONIC CF-19 (see Fig.
4.15). It contains the operative system windows XP and the pre-installed control and data
acquisition software IBIS-S Controller v. 02.01.004.
Fig. 4.15 – PC Panasonic CF-19
Characteristics of the supplied model are:
• Intel Core Duo Processor U2400;
• 100 Mb/s Ethernet card;
• RAM 512 MB memory ;
• max monitor resolution 1024x768 pixels;
• max number of colours 16 777 216 colours;
• Windows XP Professional operative system;
• HDD 80 GB, shock-proof (mounted on gel support or equivalent);
• Protection from atmospheric agents (conforms with IP54);
• No communication software such as Firewall, WiFi or antivirus must be installed
to avoid any conflict with the IBIS-S Controller software.
The notebook is supplied with a network power supplier (220V) and a battery power
supplier (12V). The latter permits to supply the notebook using the battery or the 12V
plug of a car.
NOTA: IDS takes no responsibility for malfunctioning if there is a functional conflict between
its software and any software installed on the notebook PC by the user. IDS does not
guarantee that the performance of its equipment will be maintained using a
configuration different to that recommended.
