Here below you can see the requirements and steps to connect by wireless DAD to
PC:
1) System requirement: wireless network board of PC must support
network protocol type 802.11g.
2) Disconnect Lan cable from DAD and from PC.
3) Connect the wireless plug on LAN port of the DAD (Fig. 4.1 e Fig.
5.7).
4) Activate wireless network on PC choosing “ON” with the button on
relative port shown in Fig. 5.6.
5) Set up wireless board on PC with the following IP address:
192.168.200.195.
6) Disable all boards present within “network connections” window on
PC.
7) Switch off PC and reboot operating system.
8) Enable wireless board.
9) Switch on the DAD.
10) Wait for signal on PC of activating connection RIS K2.
11) Launch the acquisition software icon setting up a Wi-Fi configuration
file: you can recognize them from the label “WiFi” (see Fig. 5.8).
Fig. 5.6 – Wireless port to be activated on CF-19
WIRELESS
ON
