3. CABLING
Take the two antenna cables: link connector 1 to the Ant.1 port of one of
the DAD (Fig. 3.1), then do the same for connector 2 and the other DAD.
Fig. 3.1 – Antenna cable connection
Connect the wheel cable of the trolley with the wheel port of DAD n.1
(Fig. 3.2)
Fig. 3.2 – Wheel cable
Wheel cable
