Datasheet

61.5
1
82.5
74.5
67
35
ø5.2
ø6
94
14
10.5
A
One color (2-core)
Three-color alternate (4-core)
A=1m
,
3m
,
5m
A=1m, 3m
,
5m
A=1m, 3m, 5m
R2.6
A=300
M12 connector
Partial stripping
Two-color alternate (3-core)
ø66
74.5
±0.5
82.5
±0.5
35
±0.1
∗To install, use two M5
screws, one each on the
top and bottom.
2-M5 screw
Top
Bottom
5
LH Series Surface Mount Indicators
Jumbo Dome Type
Types
Package Quantity: 1
Shape Types Ordering Type No. Illumination Color
Jumbo Dome
(ø66) One color
Cable
1m
LH1D-D3HQ4C10
Specify a color code in place of  in the Type No.
Color code: A, G, PW, R, S, W, Y
3m
LH1D-D3HQ4C30
5m
LH1D-D3HQ4C50
Connector
LH1D-D3HQ4CN1
Jumbo Dome (ø66)
2-color alternate
Cable
1m
LH1D-D3HQ4C10
Specify a color code in place of / in the Type No.
Color code: R/G, G/W, R/W, A/G, A/W, R/PW, G/PW, A/PW
(Two-color alternate)
3m
LH1D-D3HQ4C30
5m
LH1D-D3HQ4C50
Connector
LH1D-D3HQ4CN1
Jumbo Dome (ø66)
3-color alternate
Cable
1m
LH1D-D3HQ4C10
Specify a color code in place of // in the Type No.
Color code: R/G/W, R/G/PW
(Three-color alternate)
3m
LH1D-D3HQ4C30
5m
LH1D-D3HQ4C50
Connector
LH1D-D3HQ4CN1
Color code: A (amber), G (green), PW (pure white), R (red), S (blue), W (white), Y (yellow). •
For orange, specify “A ” (for amber). •
Dimensions
Cable color: White / Connector pin No. 4
Cable color: Brown / Connector pin No. 3
Cable color: Green / Connector pin No. 2
LED module (color: ➀)
Connector pin No.1
(N.C.)
(N.C.)
Internal Circuit
Lens Colors
Illumination Color Lens Color
One Color
Amber (A)
Green (G)
Pure White (PW)
Red (R)
Blue (S)
White (W)
Yellow (Y)
Amber
Green
White
Red
Blue
White
Yellow
Two-color
Alternate
Red (R) / Green (G)
Green (G) / White (W)
Red (R) / White (W)
Amber (A) / Green (G)
Amber (A) / White (W)
Red (R) / Pure White (PW)
Green (G) / Pure White (PW)
Amber (A) / Pure White (PW)
White
White
White
White
White
White
White
White
Three-color
Alternate
Red (R) / Green (G) / White (W)
Red (R) / Green (G) / Pure White (PW)
White
White
Resistor
LED Chip
Rectifying Diode
Zener Diode
Connector pin No. 1
(N.C.)
Cable color: White / Connector pin No. 4
Cable color: Green / Connector pin No. 2
Cable color: Brown / Connector pin No. 3
LED module (color: ➁)
LED module (color: ➀)
Three-color Alternate Illumination •
Cable color: White / Connector pin No. 4
Cable color: Brown / Connector pin No. 3
Cable color: Green / Connector pin No. 2
Cable color: Yellow / Connector pin No. 1
LED module (color: ➀)
LED module (color: ➁)
LED module (color: ➂)
LED Module Internal Circuit
The schematic of the LED module internal circuit differ depending
on the illumination color.
Illumination color: A, R, W • Illumination color: G, PW, S •
Two-color Alternate Illumination •
One-color Illumination •
Mounting Hole Layout
All dimensions in mm.
Note: For the schematic of the LED module, see "LED Module Internal Circuit" on the right.
