Modular Plug Termination and Prep Tools
Electrician’s Scissors 35-088
Adjustable Ringer Jacket Stripper 45-165
Ratchet Telemaster™ Modular
Plug Crimper 30-696
Telemaster™ Modular
Plug Crimper 30-496
Telemaster Starter Kit 33-700
Data/Voice Modular Plug
Crimp Kit 33-396
FT-45™ Feed-Thru Modular
Plug Crimp Tool 30-495
FT-45™ Replacement Blade 30-4951
Twisted Pair Termination Hip Kit 33-508
Feed-Thru RJ-45 Installation
Hip Kit 33-507
PrepPRO
®
UTP/Coax
Cable Stripper 45-605
Connector & Tool Compatibility Chart
IDEAL CONNECTOR
30-495
FT-45™
30-696
Ratchet
Telemaster™
30-496
Telemaster™
33-396 Data/
Voice Crimper
CAT6A/6/5e Shielded Feed-Thru RJ-45
CAT6 Feed-Thru RJ-45
CAT6 Single Piece Standard RJ-45
CAT6 3-Piece Standard RJ-45
CAT5e Feed-Thru RJ-45
CAT5e Shielded RJ-45
CAT5e Shielded Feed-Thru RJ-45
CAT5e Standard RJ-45
RJ-11/12 Voice Plug
RJ-11 Voice Plug
Modular Plugs
Name
CAT
Type Feed-Thru Shield
Notes
Quantity Part No.
CAT6A/6/5e
Shielded
Feed-Thru
Multi
RJ-45
8P8C
For shielded or unshielded CAT6A,
CAT6 or CAT5e with insulated
conductor diameter of 0.040” to
0.048”, max. jacket diameter of .320”
Card of 25 85-368
Jar of 50 85-369
CAT6
Feed-Thru
6
RJ-45
8P8C
For unshielded CAT6 with 23 or 24
AWG conductors with a max. insulated
conductor diameter of 0.041”, max.
jacket diameter of .290”
Card of 25 85-375
Card of 50 85-376
Bag of 100 85-377
Jar of 100 85-377J
CAT6
Single
Piece
Standard
6
RJ-45
8P8C
For unshielded CAT6 with 23 or 24
AWG conductors with a max. insulated
conductor diameter of 0.041”, max
jacket diameter of .290”
Card of 25 85-367
Jar of 100 86-367J
CAT6
3-Piece
Standard
6
RJ-45
8P8C
3 piece assembly of body, sled and
liner. For unshielded CAT6 with 23 or
24 AWG conductors with a max.
insulated conductor diameter of
0.041”, max. jacket diameter of .290”
Card of 25 85-366
CAT5e
Feed-Thru
5e
RJ-45
8P8C
For unshielded CAT5e with 23 or 24
AWG conductors with a max. insulated
conductor diameter of 0.041”, max.
jacket diameter of .270”
Card of 25 85-370
Card of 50 85-371
Bag of 100 85-372
Jar of 100 85-372J
CAT5e
Shielded
Feed-Thru
5e
RJ-45
8P8C
For shielded CAT5e with 24 AWG
conductors with a max. insulated
conductor diameter of 0.041”, max.
jacket diameter of .270”
Card of 25 85-365
CAT5e
Shielded
5e
RJ-45
8P8C
For shielded CAT5e with 24 AWG
conductors with a max. insulated
conductor diameter of 0.041”, max.
jacket diameter of .270”
Card of 25 85-361
CAT5e
Standard
5e
RJ-45
8P8C
For unshielded CAT5e with 23 or 24
AWG conductors with a max.
insulated conductor diameter of
0.041”, max. jacket diameter of .270”
Card of 10 85-147
Card of 15
(includes 15
Strain Relief
Boots)
85-379
Card of 25 85-346
Card of 50 85-396
Bag of 100 86-396
Jar of 100 86-396J
Snagless
Strain
Relief Boot
5e/6
RJ-45
8P8C
Blue color, slide on snagless boot,
max. cable diameter of 5.5mm/.220”
Card of 25 85-380
6-Contact
Voice Plug
3
RJ-
11/12
6P6C
6-position, 6-contact voice grade
modular plug, max. 24 AWG
conductors
Card of 25 85-345
4 Contact
Voice Plug
3
RJ-11
6P4C
6-position, 4-contact voice grade
modular plug, max. 24 AWG
conductors
Card of 25 85-344
