Product Manual

17
Oct. 2018
U-2200IEH-XR
29 M-2200IEH-XR-029 JP24-00001-000 Pin #1 2
30 M-2200IEH-XR-030 5603-20025-000 Bearing, D20 x D23 x 25mm 8
31 M-2200IEH-XR-031 5304-00020-000 Circlip, D20 14
32 M-2200IEH-XR-032 JP24-00002-000 Pin #2 2
33 M-2200IEH-XR-033 5206-00020-000 Lock Nut, M20 2
34 M-2200IEH-XR-034 5302-00025-000 Flat Washer, D25 2
35 M-2200IEH-XR-035 JP24-00003-000 Pivot Bolt 2
36 M-2200IEH-XR-036 5603-25025-000 Bearing, D25 x D28 x 25mm 8
37 M-2200IEH-XR-037 JP24-00005-000 Down Roller 2
38 M-2200IEH-XR-038 5302-00020-000 Flat Washer, D20 8
39 M-2200IEH-XR-039 5304-00025-000 Circlip, D25 2
40 M-2200IEH-XR-040 JP24-14000-000 Safety Latch (LH) 1
40-1 M-2200IEH-XR-040.1 JP24-14100-000 Latch Frame (LH) 1
40-2 M-2200IEH-XR-040.2 5107-03008-000 Screw, M3 x 8mm 8
40-3 M-2200IEH-XR-040.3 JP24-13004-000 Mount Plate 2
40-4 M-2200IEH-XR-040.4 5302-00005-000 Flat Washer, D5 8
40-5 M-2200IEH-XR-040.5 5303-00005-000 Lock Washer, D5 4
40-6 M-2200IEH-XR-040.6 5110-05012-000 Screw, M5 x 12mm 8
40-7 M-2200IEH-XR-040.7 MK01-00300-000 Electromagnet 2
40-8 M-2200IEH-XR-040.8 5305-00006-000 Circlip, D6 4
40-9 M-2200IEH-XR-040.9 JP24-13003-000 Latch Pin 3
40-10 M-2200IEH-XR-040.10 JP24-00016-000 Latch Cover 2
40-11 M-2200IEH-XR-040.11 5110-04020-000 Screw, M4 x 20mm 2
40-12 M-2200IEH-XR-040.12 JP24-13001-000 Linkage Arm - Long 2
40-13 M-2200IEH-XR-040.13 5206-00004-000 Lock Nut, M4 8
40-14 M-2200IEH-XR-040.14 JP24-13200-000 Rocker Arm 2
40-15 M-2200IEH-XR-040.15 5110-04012-000 Screw, M4 x 12mm 6
40-16 M-2200IEH-XR-040.16 JP24-13002-000 Linkage Arm - Short 2
40-17 M-2200IEH-XR-040.17 JP24-13300-000 Latch 2
41 M-2200IEH-XR-041 JP24-00004-000 Upper Roller 4
42 M-2200IEH-XR-042 JP24-03000-000 Outer Scissor Frame 1
43 M-2200IEH-XR-043 JP24-02000-000 Inner Scissor Frame 1
44 M-2200IEH-XR-044 JP24-13000-000 Safety Latch (RH) 1
44-1 M-2200IEH-XR-044.1 JP24-13100-000 Safety Latch Frame (RH) 1
45 M-2200IEH-XR-045 JP24-00010-000 Cable Spring Cover #1 4
46 M-2200IEH-XR-046 5110-04006-000 Screw, M6 x 6mm 10
47 M-2200IEH-XR-047 JP24-00009-000 Cable Bracket 10
48 M-2200IEH-XR-048 MK01-00003-000 Rubber Grommet 8
49 M-2200IEH-XR-049 JP24-00012-000 Cable Spring Cover #3 1
49-1 M-2200IEH-XR-049.1 MK01-00301-000 Latch Cable #1 1
50 M-2200IEH-XR-050 JP24-00011-000 Cable Spring Cover #2 1
50-1 M-2200IEH-XR-050.1 MK01-00401-000 Latch Cable #2 1
51 M-2200IEH-XR-051 JP02-00007-000 Grease Zerk, M6 8
52 M-2200IEH-XR-052 JP24-00024-000 Cylinder Pin - Long 1
53 M-2200IEH-XR-053 JP23-05000-E00 Base Frame 1
54A M-2200IEH-XR-054A JP23-04000-000 Cylinder (2200IEH-XR) 1
54-1 M-2200IEH-XR-054.1 JP23-04100-000 Cylinder Body 1
54-2 M-2200IEH-XR-054.2 BZ20-04026-000 Compensate Valve 1
