Product Manual

16
Oct. 2018
U-2200IEH-XR
Exploded Views – (Lift Structure)
Parts List - (Lift Structure)
ITEM Tux P/N M-Ref P/N DESCRIPTION QTY
3 M-2200IEH-XR-003 JP23-08000-E00 Rear Pivot Panel 1
4 M-2200IEH-XR-004 JP23-01000-E00 Platform 1
5 M-2200IEH-XR-005 JP17-00011-000 MC / UTV Wheel Stop 3
6 M-2200IEH-XR-006 JP02-00009-000 Eye Bolt, M10 4
7 M-2200IEH-XR-007 JP23-00003-E00 Rubber Pad 4
8 M-2200IEH-XR-008 5202-00006-000 Lock Nut 6
9 M-2200IEH-XR-009 5103-06050-000 Bolt, M6 x 50 2
10 M-2200IEH-XR-010 JP23-00001-000 Balance / Stabilizer Bar 1
11 M-2200IEH-XR-011 JP17-00010-000 Sleeve 2
12 M-2200IEH-XR-012 JP24-00025-000 Hinge Pin 2
13 M-2200IEH-XR-013 5304-00012-000 Circlip, D12 6
14 M-2200IEH-XR-014 5302-00012-000 Flat Washer, D12 2
15 M-2200IEH-XR-015 JP23-00001-E00 Pin, Pivot Panel 1
16 M-2200IEH-XR-016 JP27-00013-000 Spring 2
17 M-2200IEH-XR-017 5115-06012-000 Screw, M6 x 12mm 4
18 M-2200IEH-XR-018 JP23-00002E00 Yellow Safety Strip, Ramp 1
27 M-2200IEH-XR-027 5206-00005-000 Lock Nut, M5 1
