User's Manual




InstallationGuidefortheiHub3000BADTandtheConcord4SecurityPanel
ActivatingtheServicewithConcord4SecurityPanel
Beforeyoubegintheactivationprocess,youmustmakesomehardwareconnections.Sinceeach
securitypanelisdifferent,followtheinstructionsinthenextsection,"
ConnectingtheHardware
",for
thespecificsecuritypanelyouareinstalling.Thenpleasefollowtheinstructionsin
"Activatingthe
Service"onpage3forallsecuritypanels.
ConnectingtheHardware
Followtheprocedureinthissectionthatappliestothesecuritypanelyouareinstalling.
Note: DonotconnecttheiHubgateway'spowersupplytoanelectricaloutletuntilyou
areinstructedtodosobytheactivationwizard.Ifyoupoweronthegatewaybeforeitis
connectedtotheInternet,itcannotretrievetheinformationitrequiresonpowerup.Ifyou
havealreadydonethis,simplyunplugitandcontinuewiththefollowinginstructions.
IfyouareinstallingaTouchScreen,donotconnectittoapowersourceuntilyouare
instructedtodosobytheactivationwizard.
ToconnectthegatewaytotheConcord4securitypanel:
1. WiretheAutomationModuletotheConcord'sbus,asdescribedintheGEInstallationManual.
2. GatewaymodeliHub3000BADT,connectorsarelabeledTx+,Tx,Rx+,andRx.Theautomation
moduleconnectorsarelabeledthesamebutmightincludea/binsteadof+/.Usingastandard4
wiresecuritycable,connecttheportsonthegateway'sRS422bustotheAutomationModuleas
follows:
Gateway AutomationModule
Tx+ Rx+orRxb
Tx‐ Rx‐orRxa
Rx+ Tx+orTxb
Rx‐ Tx‐orTxa
DonotconnectanyantennaprovidedtotheportonthegatewaylabeledCellular.Cellular
communicationsfromtheiHubarenotused.
ActivatingtheService
Toactivatetheservice:
1. OnacomputerconnectedtotheInternet,openawebbrowser,andgototheactivationURL
portal.adtpulse.com/activation
.
2. Enteryourusernameandpassword,andclickSignIn.
TheactivationwizarddisplaystheWelcomescreen.
3

