User's Manual




InstallationGuidefortheiHub‐3000B‐ADTandtheConcord4SecurityPanel
Specifications,ApprovalsandCertifications.
LAN 1 (10/100 Mbit/sec port) Ethernet
WAN 1 (10/100 Mbit/sec port)
WiFi IEEE 802.11b/g Wireless
Z-Wave Built-in Z-Wave module
Wired Control
Interface
RS422 1 (External RS422 by screw terminal connector)
USB 2 (for future expansion)
JTAG 1 (for development / debug)
Applications Linux 2.4 BSP Ready Software
Web Browsers Broadcom BCM5354 Web Interface
Processors and
memory
SoC: Broadcom 5354
SDRAM: DDR 32 MB
Nor Flash 32 MB
Connectors DC Power Jack
Screw Terminal for RS422
2 RJ-45 for Ethernet LAN and WAN
2 USB for external USB device
LED and Button LED: Power, Broadband, Devices
Button: Reset, Sync
Antenna 1 WiFi Dipole antenna
1 Z-Wave internal antenna
Power
Consumption
12 DC, Max 10.5W Compliance FCC, CA
Power Supply: UL
Hardware
Dimensions
(H x W x D)
235 x 160 x 40mm
(9.3" x 6.3" x 1.57")
Weight 590g (1.3 lb)
Environment Operation: Temperature: 0 - 40°C (32° - 104°F); Humidity: 10% - 80% RH (non-condensing)
Storage: Temperature: -20 - 70°C (-4° - 158°F); Humidity: 0% - 90% RH (non-condensing)
Accessories Powered Supply (12V / 1A, 100-240VAC)
