SUPPLIED ACCESSORIES AND ATTACHMENTS

■ Attachments (Continued)

D Handstrap

Pass the handstrap through

the loop on the back side of

the transceiver to make it

easy to carry.

D Belt clip

Attach or detach the belt clip to/from the transceiver as

shown below.

Belt clip

To attach the belt clip To detach the belt clip

BE CAREFUL!

Do not break

your ngernail.

Lift the tab up q and slide the belt clip

in the direction of the arrow w.
