Operation Manual

OTHER FUNCTIONS

‘‘

DTMF PAGER/CODE SQUELCH

DTMF pager

This function uses DTMF tones for calling and can be used as a

“common pager” to inform you that one of your group has called

even if the operator is temporarily away from the transceiver.

• When the connection code is received, a beep sounds, then “ ”

flashes and shows the called station’s code number.

• The called station’s code number is memorized automatically, and

is easy to re-call with “ID-MR select function”.

Code squelch

This conveniently eliminates unwanted audio and is useful in group

activities or security related activities where unwanted output can

be a problem. The function is similar to a CTCSS tone squelch.

In order to use the above functions, cloning is necessary via a

PC using the optional CS-F30G

CLONING SOFTWARE

. Using this

software, the transceiver’s model, individual RX Code CH, TX

Code CH, Special Tone Link2 (must be ‘E’) in 5Tone screen,

5Tone Signaling Form in Memory-CH screen, Log, RX C-No,

Key&Display, Common Auto Reset Timer B, and other settings

related to operation can be set. Refer to the HELP ﬁle that comes

with the CS-F30G

CLONING SOFTWARE

for available settings.

‘‘

Cloning

Cloning allows you to quickly and easily transfer the programmed

contents or data from PC to a transceiver using the optional CS-

F30G

CLONING SOFTWARE

PC-to-transceiver cloning

Please refer to the HELP ﬁle that comes with the CS-F30G

CLONING

SOFTWARE

CAUTION: Imprudent cloning operation causes a cloning error. In such

a case, memory contents may be lost. Cloning must then be repeated.
