BATTERY PACKS
‘‘
Battery pack replacement
Before replacing the battery pack, the volume control MUST be ro-
tated fully counterclockwise, until a click is heard, to turn the power
OFF.
• Slide the battery release forward, then pull the battery pack up-
ward with the transceiver facing away from you.
DD
BATTERY PACKS
*
1
Battery life is calculated under the following conditions;
Tx : Rx : standby =5 : 5 : 90
*
2
Operating period depends on alkaline cells used.
Charging period
Battery
Voltage Capacity
BC-119N or
Battery life*
1
pack BC-137 BC-121N
with AD-101
BP-208
Battery case for AA
N/A N/A —*
2
(R6)×6 alkaline
BP-209 7.2 V 1100 mAh 15 hrs. 1.5 hrs. 7 hrs.
BP-210/FM 7.2 V 1650 mAh 15 hrs. 2.0 hrs. 11 hrs
BP-211 7.4 V 1800 mAh N/A 2.0 hrs. 12 hrs
The BP-210FM only can
be used for the intrinsically
safe versions.
