SERVICE/INSTALLATION MANUAL ICE ONLY DISPENSERS MODELS-IOD150, IOD200 AND IOD250 Mile High Equipment 11100 East 45th Ave Denver, Colorado 80239 Part Number 9081305-01 Print Date 06/02
Introduction IOD150,IOD200,IOD250 To the owner or user: This product manual is a source of information about the installation, start up, cleaning, maintenance and repair of the product. The IOD150, IOD200 and IOD250 are ice only counter top dispensers designed to use 22 inch wide and 30 inch wide respectfully Ice-O-Matic cubed ice machines as the source of ice. The IOD ice dispenser is a machine that stores ice in an insulated, sanitary container: upon demand it dispenses that ice into a cup or glass.
Specifications and Limitations IOD150, IOD200, IOD250 Limitations: Must meet the same limitations as the cuber installed on top of it: 50° F. air minimum 100° F. air maximum Must be installed indoors. Must allow at least 6-inch clearance at the rear and both sides when using an air-cooled ice machine. Must allow space for the utility connection at the back. Must have a drain.
For The Installer IOD150, IOD200, IOD250 Equipment Description The IOD150, IOD200 and IOD250 are counter top mounted ice only dispensers. These units are designed to dispense cube ice only and have ice storage capacities of 150 lb.,220 lb. and 250 lb. respectively. Site Preparation The site chosen for the dispenser must be capable of supporting the dispenser with a full bin of ice plus all other loads being placed on the surface supporting the dispenser.
Installation IOD150, IOD200, IOD250 1. Locate the ice dispenser on the counter. Allow vertical clearance above the unit for the removal of the cover and for pouring ice into the hopper. 2. Plan the unit drain. A one-inch (1”) I.D. drain tube is required for draining. Routing is either through the back or the base. Sufficient fittings are included with the unit to install in most cases. 3.
Water Glass Filler Kit IOD150, IOD200, IOD250 Installation Instructions WARNING: Disconnect power to unit before proceeding with installation. 1. Prepare the unit as follows: ·Remove the lower front panel ·Locate faucet-mounting holes in the front panel. (Reference page 6 for hole locations) 2. Install faucet and tubing assembly as shown below. 3. Connect field water supply to ¼ male flare fitting on tubing assembly. Apply water pressure and check all connections for leaks.
Water Glass Filler Kit (Con’t) IOD150, IOD200, IOD250 Faucet mounting hole locations. IOD150 Dimensions A B 4.0 Inches 2.5 Inches IOD200 and IOD250 Dimensions A B 6.125 Inches 3.125 Inches The water inlet tubing can be routed either from the back or from underneath the dispenser. If from the back, remove the back and bottom access panels.
Initial Start Up IOD150, IOD200, IOD250 1. Sanitize the ice storage system as instructed on Page 10. 2. Fill the hopper with sanitary ice. 3. Plug the unit’s power cord into an electrical outlet and the lighted sign should come on. 4. Dispense several containers of ice. Note: In normal operation, pushing the ice dispenser mechanism will cause ice to flow from the ice chute. Ice flow will continue until the dispenser mechanism is released or until the hopper runs out of ice.
Gate Restrictor Plate IOD150, IOD200, IOD250 CAUTION: Disconnect power to dispenser and ice machine before installing, removing or adjusting restrictor. ADJUSTMENT This plate may be adjusted as shown to reduce or increase the dispensing rate of ice, especially desirable when using glasses or other containers with small openings. Adjustment can be made by sliding up or down with the nuts loosened, to obtain the desired amount of restriction.
Cleaning and Sanitizing IOD150, IOD200, IOD250 The sink, grill and splash panel area should be cleaned daily. The following dispenser maintenance should be performed at the intervals indicated: Daily (Or As Required) Remove foreign material from vending area drip tray to prevent drain blockage. Weekly (Or As Required) Clean vending area. Check for proper water drainage from the vending area. Monthly Clean and sanitize the hopper interior.
Cleaning and Sanitizing IOD150, IOD200, IOD250 MONTHLY AND INITIAL START UP: Sanitize the Ice Storage System. Note: This should be done by qualified personnel. CLEANING PRECAUTIONS WARNING: Disconnect Power Before Cleaning! Do not use metal scrapers, sharp objects or abrasives on the ice storage hopper, top cover and the agitator disk, as damage may result. Do not use solvents or other cleaning agents, as they may attack the plastic material.
Troubleshooting IOD150, IOD200, IOD250 IMPORTANT: only qualified personnel should service internal components or electrical wiring. Should the dispenser fail to operate properly, check that there is power to the unit and that the hopper contains ice. If the unit does not dispense, check the following chart under the appropriate symptoms to aid in locating the defect. TROUBLE PROBABLE CAUSE Blown fuse or circuit breaker. A. Short circuit in wiring. B. Defective gate solenoid. C.
Wiring Diagram IOD150, IOD200, IOD250 Page 12
