USER MANUAL
4.3 STATUS LED
„Start-up“ mode
Green
Red
„Not connected“ mode
Green
Red
„Connected“ mode
Green
Red
„Pairing“ mode
Green
Red
Error codes
Example three times:
Green
Red
Blinking Description
3 x Undervoltage (<6,5V for 1,5s)
4 x Overvoltage (>36V for 60ms)
5 x Sum of separate currents too high (>10A; e.g. short circuit)
6 x Overcurrent output 1
7 x Overcurrent output 2
8 x Overcurrent output 3
9 x Overcurrent output 4
-> Please see chapter 8 of this manual to solve the errors!
Example:
Green
Red
Explanation
= ON = OFF
For the above example this means:
Green light ON for 0.5 seconds while red light is o
-> Green light turns OFF while red light turns ON
for 0.5 seconds.
0 0.5
sec
1.0
