USER MANUAL
1. TECHNICAL SPECIFICATIONS
Frequency 2,4 GHz
Transmission power 7,5 dBm
Operating range approximately 30m
Power consumption ~4mA on 12V
Supply voltage 9-36 Vdc
Outputs 4 (3.7A, nominal 4.7A each)
Total current max. 10A
Dimensions 79mmx 87mm x 26mm (L x W x H)
Weight 138g
Casing moulded casing (IP66)
Temperature range -40°C to +80°C
Optical feedback Dual colour LED (red / green)
Platform Android and iOS
Max. number of paired devices 24
Min. system requirements Android 4.3 and Bluetooth 4.0
iOS 8, iPhone 4s / iPad, 3rd gen. / iPod Touch, 5th gen.
2. PRODUCT TYPE IDENTIFICATION
Each ICARUS blue receiver is labelled (on the rear side) with a sticker containing the product name icon, a QR-code having
an unique production / serial number, the product type identification, the supply current and some symbol designations.
An example of a device label is given below.
