USER MANUAL (90010000 STANDARD) A PRODUCT OF THE ICP GROUP | WWW.ICPGROUP.EU V.2.11.
USER MANUAL ABOUT THIS USER MANUAL This user manual is intended for end-users and installers of these receivers. The purpose of this manual is to provide the user with all necessary information to ensure a correct, efficient and safe use of the product (during its lifetime), even in the event of a reasonably foreseeable misuse. This manual is designed to facilitate the installation, commissioning, use, maintenance and disposal of the non-return modules.
USER MANUAL SAFETY REGULATIONS General The user should have read this user manual before using the device for the first time and its content should have been understood. If there are questions and / or uncertainties before the first use, you need to contact your supplier for clarification. This user manual must also be included when this device is used by any third party. Therefore: • Losses incurred as a result of not going through the safety-requirements is not covered under warranty.
USER MANUAL TABLE OF CONTENTS 1. Technical specifications ......................................................................................................... 4 2. Product type identification .................................................................................................... 4 3. The product‘s purpose (and usability) .................................................................................... 5 4. ICARUS blue receiver ...........................................................
USER MANUAL 1. TECHNICAL SPECIFICATIONS Frequency Transmission power Operating range Power consumption Supply voltage Outputs Total current Dimensions Weight Casing Temperature range Optical feedback Platform Max. number of paired devices Min. system requirements 2,4 GHz 7,5 dBm approximately 30m ~4mA on 12V 9-36 Vdc 4 (3.7A, nominal 4.7A each) max. 10A 79mmx 87mm x 26mm (L x W x H) 138g moulded casing (IP66) -40°C to +80°C Dual colour LED (red / green) Android and iOS 24 Android 4.3 and Bluetooth 4.
USER MANUAL 3. THE PRODUCT‘S PURPOSE (AND USABILITY) ICARUS blue is an app-controlled wireless receiver, with impressive features such as a compact and sturdy design, a legion of universal application possibilities and a low purchase price.
USER MANUAL 4.1 INSTALLATION REQUIREMENTS • • • • • • • • Always make sure you are using a clean, tidy and dry working surface. Unplug the ICARUS blue receiver before installation and assembly from a connected power source. Install the ICARUS blue receiver in sight of the user, if possible. DO NOT install the ICARUS blue receiver in the immediate vicinity of motors, relays or power cables. DO NOT install the ICARUS blue receiver on the inside of a metal casing (this limits the connection range).
USER MANUAL 4.2 CABLE CONNECTIONS Function 0Vdc 9-36V Output 1 Output 2 Output 3 Output 4 A PRODUCT OF THE ICP GROUP | WWW.ICPGROUP.
USER MANUAL 4.3 STATUS LED „Start-up“ mode Example: Green Green Red Red „Not connected“ mode Green 0 0.5 sec 1.0 Explanation Red = ON „Connected“ mode = OFF For the above example this means: Green light ON for 0.5 seconds while red light is off -> Green light turns OFF while red light turns ON for 0.5 seconds.
USER MANUAL 4.4 ACTIVATE/DEACTIVATE PAIRING MODE (TEACH-IN BUTTON) The teach-in button of the ICARUS blue receiver is intended to activate the pairing functionality of the receiver. STEP 1 Please connect the supplied cable to the receiver. Please use exclusively the provided plug! STEP 2 Provide the receiver with power. Red cable = 9-36Vdc, Black cable = 0Vdc (see 4.
USER MANUAL 5.1 OVERVIEW / HOME SCREEN MENUBUTTON NAME OF CONNECTED RECEIVER CONTROL BUTTONS Possible button-statuses: REGULAR - Button is NOT pressed/touched - Output is NOT active BOLD BORDER - Button is pressed/touched - Output is NOT active DARK BACKGROUND - Button is NOT pressed/touched - Output is active BOLD BORDER AND DARK BACKGROUND - Button is pressed/touched - Output is active A PRODUCT OF THE ICP GROUP | WWW.ICPGROUP.
USER MANUAL 5.2 ADDING A NEW RECEIVER ATTENTION: To add a new receiver, the receiver must be in „pairing-mode“ (see 4.4). Please make sure that there is no more than one receiver in„pairing-mode“ at the same time. STEP 1 Open the main menu via the button at the top left and select the menu item „New receiver“. STEP 2 The app will automatically search for ICARUS blue receivers within your range, that are currently in „pairing mode“ (see 4.4).
USER MANUAL 5.3 SWITCHING BETWEEN SEVERAL RECEIVERS This step-by-step instruction assumes, that you have already paired two or more ICARUS blue receivers to your smartphone. If this is not the case, you first have to add additional ICARUS blue receivers (see 5.2). STEP 1 Open the main menu via the button at the top left and select the menu item „Device manager“. STEP 2 You‘ll now see a list of all receivers, that have already been paired with your smartphone in the past.
USER MANUAL 5.4 MAINFUNCTIONS Once you have paired and connected a receiver to your smart device, you can control and configure the buttons / outputs as you wish with the ICARUS blue app. Please open the main menu of the app (top left corner) and select the „settings“ menu item.
USER MANUAL 5.5 ADVANCED OUTPUT OPTIONS 5.5.1 TIMER FUNCTIONS The ICARUS blue app offers a variety of advanced options for every button / output. By pressing the „Advanced“-button in the „Output Settings“-screen, you will get the following options: Timer disabled (selected by default): If this option is activated, the output has no timer function. Output signal Switching state OUTPUT-ON DELAY EXAMPLES (1 SECOND DELAY) I 0 0 1 2 3 4 5 6 7 8 9 10 11 sec. 0 1 2 3 4 5 6 7 8 9 10 11 sec.
USER MANUAL 5.5.2 OUTPUT CONTROL (INTERLOCK) Setting an interlock between two or more buttons will prevent the outputs from being active at the same time. Please proceed with 5.5.3 5.5.3 OUTPUT SELECTION AND BUTTON-VISIBILITY The selected outputs are activated if button is pressed. You have the choice to make the Button of the additional output visible or not. Note: Timer or other settings can influece the output. Please press „Next“ and then „Save“ to confirm all changes.
USER MANUAL 5.
USER MANUAL 5.7 APP-SETTINGS To get to the app-settings, first open the main menu on the top left and then select the menu item „Settings“. On the lower edge of the following screen please press the „App-Settings“ button. In the App-Settings you have the following options: 5.7.1 Restore factory settings This option will reset all output functions to default. 5.7.2 Set password If a password is entered, the output settings are password protected.
USER MANUAL 6. USING THE DEVICE Improper operation, by NOT having read the user manual and having full understanding of it as well as how to use the device, can bring the operator, bystanders and other matters in danger, depending on its application, and may cause personal injury and / or damage to personal possessions as well as to the device. 7. MAINTENANCE AND CLEANING The product is maintenance-free for the user. Maintenance and repairs must be done by a specialist.
USER MANUAL 9. DISPOSAL Electronic devices are recyclable waste and DO NOT belong in the garbage. If the product does not work anymore, dispose it in accordance with applicable legal regulations. By following the above recommendation you comply with your legal obligations and contribute to the protection of the environment. 10.
USER MANUAL 11. DECLARATION OF CONFORMITY (ORIGINAL) Declaration of Conformity Manufacturer ICP Systems B.V. Handelsweg 48, 7451PJ Holten, The Netherlands. Plant ICP Systems B.V. Handelsweg 48, 7451PJ Holten, The Netherlands.
