MultiStorage Device Installation and Service Guide

Asm–
Index
Part
Number
Units Description
1–1 45P6211 1 LED panel
–2 03R5908 1 System board (31x)
–2 03R5973 1 System board (32x)
–3 16K9262 1 128-MB DIMM
– 45P6236 1 256-MB DIMM
– 03R5924 1 512-MB DIMM
–4 45P6205 1 Compact Flash mount
–5 45P6203 1 64-MB Compact Flash
– 45P6235 1 128-MB Compact Flash
– 45P6209 1 Riser card (31x, not shown)
– 03R5968 1 Riser card (32x, not shown)
– 45P6222 1 Battery (not shown)
–6 03R5912 1 HDD
–7 03R5911 1 HDD bracket
– 45P6206 1 HDD cable (not shown)
–8 45P6090 1 CPU heat sink (31x)
–8 03R5953 1 CPU heat sink and fan (32x)
–9 47P9036 1 866 MHz CPU (31x)
–9 03R5970 1 1.2 GHz CPU (32x)
– 45P6213 1 Parts kit (not shown)
–10 45P6204 1 100 W power supply
–11 03R5929 1 Panel-mounted 15-pin connector
– 42L0098 1 Ethernet cable (not shown)
– 03R5972 1 CD port card (32x, not shown)
– 03R5969 1 Panel-mounted 9-pin serial connector (32x, not shown)
– 03R5974 1 Riser power connector (32x, not shown)
Note: For a list of field replaceable units for the printer that is bundled with 4910, refer to the SureMark
Printers Hardware Service Guide, GY27-0355. For other I/O devices bundled with the 4910, please
refer to each device’s respective service guide.
Assembly 1: (continued)
11-9-2005
Chapter 4. Parts catalog 4-3
