MultiStorage Device Installation and Service Guide

Table 1-2. Models and features (continued)
Model Base-unit standard feature
4810-W2H 40-GB HDD, Microsoft
®
Windows
®
XP Professional preloaded
4910-32H/32E/32A 40-GB HDD
Note: References in this guide to the 4810 Model 32x also apply to the 4810
Model W2H and 4910 Models 32H, 32E and 32A.
Physical dimensions
Figure 1-1 shows the dimensions of the product:
v Width: 300 mm ( 11.8 in.)
v Depth: 216 mm ( 8.5 in.)
v Height: 90 mm ( 3.5 in.)
v Weight: 3.2 kg ( 7 lb.)
Power and cooling
Attention
When installing a new power supply, be sure to set the correct input voltage
for your area or you will damage the power supply. See Figure 1-3 on page
1-4 to locate the voltage selection switch.
v Input voltage: 100 - 127 V or 200 - 240 V ac (select using switch)
v Frequency: 50 - 60 Hz (± 3 Hz)
v Power consumption: 100 W maximum; 35 W typical
A
fan contained in the power supply provides forced air cooling.
300 mm
( 11.8 i n.)
216 mm
(8.5 i n.)
90 mm
( 3.5 in.)
Figure 1-1. Dimensions of the 4810/4910 SurePOS 300 (does not include the I/O devices for the Express models)
Product introduction
