XM60 User Manual 1 Introduction The XM60 rugged mobile computer delivers all the built-in capabilities that today’s business applications demand. Plus, it’s smaller, lighter and far less expensive than comparable products. Designed for maximum value and performance, the XM60 is a cost-effective mobile solution for Windows® CE applications. About the Janam XM60 The XM60 delivers powerful computing performance packaged in a small, light and truly pocketable mobile computer.
XM60 User Manual Specifications Janam Technologies LLC 1-2
XM60 User Manual Hardware overview Indicator LED Power On/Off LCD Left Trigger Right Trigger Scan Trigger Function Backspace Home Navigation Space Programmable Shift Alpha/Numeric shift Enter Connector Top View Barcode Scan Window Janam Technologies LLC Bottom View Power On/Off Syncing/Charging Connector 1-3
XM60 User Manual Hand Strap Connector Stylus Speaker Battery Compartment IrDA Window Stylus Slot Reset Button Microphone Battery Door Battery Screw Janam Technologies LLC 1-4
XM60 User Manual 2 Get Started Unpack your Janam XM60 Make sure you have the following: • Janam XM60 handheld computer • Janam authorized battery • Hand strap • Charging accessory (ordered/packed separately) with one of the following kits: Single-slot cradle kit Four-slot cradle kit USB syncing/charging cable with AC adapter Serial syncing/charging cable with AC adapter Recommended host computer configuration/requirements The Janam XM Series Development Kit helps assist programmers with the development of
XM60 User Manual Install the battery IMPORTANT Battery Warning! CAUTION: Use only Janam-approved batteries. There is the risk of explosion if battery is replaced by an incorrect type. Always dispose of used batteries according to the instructions. 1. 2. 3. 4. To access the battery compartment, turn the locking screw counterclockwise to open the latch and remove battery cover. Position the battery lift strap against the back of battery well, ensuring tab extension is on left side.
XM60 User Manual Understanding the desktop Command bar Your XM60 mobile computer desktop includes a command bar with the following features. Toggle between desktop and applications MS Windows icon Current application USB Socket status Keypad/input panel Time/date Battery Update your ROM NOTE: ALL applications and data will be DELETED, so make sure you are properly backed up before starting this process. To check your current ROM version: 1.
XM60 User Manual To download the correct BIN file: 1. Download the latest ROM by logging in to Janam PartnerZone. (You will need a login name and password.) 2. Accept the terms and conditions, and go to PartnerZone. 3. Locate the BIN file for the XM60. If the version number matches the version on the web site, there is no need to update the ROM. 4. Click the arrow at right to begin download. Remember to store the BIN file in an easily accessible location, like your desktop.
XM60 User Manual 7. Eject the drive after update is completed. • The update ROM process will proceed. • Device will boot up within three minutes. 8. After a hard reset of the device (see next section), the new ROM will be updated in your mobile computer. To troubleshoot during ROM update: The following helps resolve any issues that might be encountered during the ROM update process. Description Resolution Explanation The scanner turns on when pressing the right scanner button.
XM60 User Manual Reset the XM60 To soft reset: In most situations, a soft reset restarts the device and saves all stored records and entries. However, any data that has not been saved will be lost during a soft reset. To perform a soft reset, do the following: 1. Remove the battery door from the back of the unit. 2. Locate the reset button. 3. Using the stylus, press the reset button (one time). 4. Replace the battery door.
XM60 User Manual 3 Barcode Scanning The XM60 provides an easy migration path so that minimal application code changes are required for barcode scanning applications. Barcode scanning demonstration and setup To run the demo: 1. Tap the MS Windows icon > programs > XM60 Applications > ScanDemo. 2. Three menus will appear (setup, OCR, options) on the top of the screen. 3. 4. 5. 6. 7. 8.
XM60 User Manual 9. Select scan. • Point the scanner at a barcode, and press any of the barcode scan trigger buttons on the XM60. The results will display after a successful scan. Enable the ScanWedge feature When the ScanWedge feature is enabled, data can be entered into the specified application by opening the application on the handheld and scanning a barcode. 1. 2. 3. 4. Go to MS Windows icon > programs > XM60 applications > ScanWedge. Select enable from the ScanWedge menu.
XM60 User Manual After receiving your five-digit key code, follow these steps to enable 2D scanning. 1. Go to the MS Windows icon > settings > XM60 panel. 2. Tap XM60 panel icon. 3. Select scanner tab. 4. Enter your five-digit key code > unlock. • A successful unlock notification will appear. 5. Press X to close the screen. Note: Remember to keep a record of your five-digit key code.
XM60 User Manual 4. 5. 6. Enter image’s name and select folder. Click OK. Below is the image that is captured. To use continuous preview: 1. Click cont or continue button. 2. Click button again to stop preview. To use intelligent capture: You can use intelligent capture to scan a signature or address that is located some distance away from a barcode. This feature supports PDF417, Code 128, Code 39 and Aztec symbologies. 1. Go to settings > intel img. 2. Set up appropriate settings.
XM60 User Manual 3. Select intel button and aim at any support barcode. If you need to capture a 2D barcode, be sure to unlock your 2D feature. Note: the image is always the same position from the barcode. 4. Select save. 5. 6. Enter image name and save to appropriate folder. Click OK. 7. The below image is captured.
XM60 User Manual Janam Technologies LLC 3-6
XM60 User Manual 4 Set up your Janam XM60 Locate front panel controls • • • Power button (on top of device). Pressing the power button turns the handheld computer on (if it is off) and returns to the last screen that was displayed. Press the power button to turn the handheld computer off. Use the backlight to illuminate the screen in low-light conditions. Hold down the power button for about two seconds to turn the backlight on and off. Janam XM60 screen.
XM60 User Manual Use the regional and language features Your Janam XM60 comes with a variety of regional, language and input settings that are preset before your device is shipped. To change these settings, follow the directions below. WARNING: If you change to a language other than English, you will have to perform a hard reset, which will erase all data on your handheld computer. If you have data you need to save, perform an ActiveSync operation before you change languages.
XM60 User Manual Remove applications To 1. 2. 3. 4. remove a program: Go to MS Windows icon > settings > control panel. Double-tap remove programs icon. Select the program you want to delete and click remove. Click OK. Enter data You can enter data into your Janam XM60 in one of five ways: • Using the stylus or touch screen with the onscreen keyboard • Scanning a barcode Customize To change owner properties on your handheld computer: 1. Tap MS Windows icon in the lower left corner of command bar. 2.
XM60 User Manual Set the date, time and time zone preferences To set the date: 1. Tap MS Windows icon in the command bar > settings > control panel. 2. Tap on calendar date to change, select new time and choose your time zone from the dropdown menu. 3. Click OK to close.
XM60 User Manual Set the display properties You can easily change the background and appearance on your Janam XM60, including the colors. In addition, you can save battery life by turning off the backlight when not needed. To change the background: 1. Tap MS Windows icon in the command bar > settings > control panel. 2. Double-tap on display icon. 3. Use the dropdown menu or tap browse to change the background on your device. 4. Tap OK. To 1. 2. 3. change the appearance: Tap on the appearance tab.
XM60 User Manual Select volume and enable sounds 1. Tap MS Windows icon in the 2. 3. 4. 5. 6. command bar > settings > control panel. Double-tap volume & sounds icon. Tap the volume tab and choose volume level and preferences. Tap OK. Tap the sounds tab, choose sound, previewing it if necessary. Click OK. Change keypad options To change key size on soft keyboard: 1. Tap MS Windows icon in the command 2. 3. 4. 5. bar > settings > control panel. Double-tap on input panel icon.
XM60 User Manual Connection Security Privacy Advanced Popups 4. After you finish making your selections in each screen, click OK to save settings. .
XM60 User Manual Janam Technologies LLC 4-8
XM60 User Manual 5 Enter Data You can enter data into your Janam XM60 handheld computer by using the stylus or touch screen with the onscreen keyboard or by scanning barcodes. • • Using the stylus or touch screen with the onscreen keyboard Scanning a barcode Use the stylus or touch screen with the onscreen keyboard You can open the onscreen keyboard when you need to enter text or numbers. To access the onscreen keyboard: 1.
XM60 User Manual To change input panels: 1. 2. 3. The standard alpha keyboard is the default. For numeric, tap on 123 keyboard in the lower left corner of the main keyboard. For international, tap on áü key, directly to the right of 123.
XM60 User Manual 6 Exchange and update Data Using ActiveSync ActiveSync technology lets you synchronize – exchange and update – data between one or more Janamconnected handheld computers and your PC using either a USB or serial cable. To synchronize data, you must connect your Janam XM60 and PC directly, place your handheld computer in the cradle attached to your computer, use a modem or use a network.
XM60 User Manual 4. 5. Select yes in the select number of partnerships screen. Click next. 6. Select the files you want to sync between your mobile device and your computer. • Note: when you select files, an additional screen appears (shown below) with further information. Read carefully before proceeding, because your files may be converted. 7. Click the settings button in the select synchronization settings screen (#6 above), and the screen at right will appear.
XM60 User Manual 11. The ActiveSync manager screen appears on your desktop. As the automatic synchronization progresses, the status bar will fill and the sync will be displayed in the status section. To 1. 2. 3. delete a partnership: Go to file > delete partnership in the ActiveSync manager. Click yes when confirmation screen appears. You will need to re-establish the partnership when you connect your Janam XM60 to your PC, or you will need to connect as a guest. To 1. 2. 3. 4.
XM60 User Manual Partnership settings To change partnership connection settings: 1. Click the ActiveSync icon in your Windows system tray (bottom right corner of taskbar). 2. Choose file > connection settings from the ActiveSync manager menu. 3. Make changes > OK.
XM60 User Manual 7 802.11 Wireless Configuration The following section details the basic 802.11 wireless configuration for your Janam XM60. Wireless local area network access To add or edit a WLAN: 1. Tap the MS Windows icon in the command bar > settings > network and dial-up connections icon. 2. Tap and hold BGW200WL1. 3. Tap enable.
XM60 User Manual 4. Tap twice on add new. 5. Enter ESSID, authentication and encryption. 6. After wireless is configured, double tap the network icon to edit or add another WLAN.
XM60 User Manual 8 Bluetooth Manager There are several ways to set up your computer for wireless access, and the following section details the general instructions needed to set up Bluetooth on your Janam XM60. Please note that complex or custom installations may require additional expertise from Janam’s technical and support team. Start Bluetooth manager To start Bluetooth manager: 1. Tap MS Windows icon in the command bar > settings > control panel. 2. Tap twice on Bluetooth device properties icon. 3.
XM60 User Manual Scan Device Wizard To 1. 2. 3. 4. 5. use Scan Device Wizard: Tap the scan device icon to start the wizard. Tap next. Wait until searching is finished. Choose the device you want to add > next. Tap finish. Bond Wizard To 1. 2. 3. 4. 5. use Bond Wizard: Tap the Bond Wizard icon. Press next. Press yes to authenticate. Insert a PIN for pairing and enter the same number on the pairing device. Tap finish to exit.
XM60 User Manual Send files Please note that your target device needs to support OBEX file transfer option. To send files: 1. In the Bluetooth Device Manager, choose send from the file menu. 2. Tap search to start searching the device. 3. When you see your target device, select it. 4. 5. 6. Choose the file you want to send. Your target device will ask you to accept the file. Transfer will start after you accept it. Wait until transfer is finished.
XM60 User Manual File browser Please note that your target device needs to support OBEX file transfer option. To 1. 2. 3. use the file browser: Choose the device you want to connect to. Input PIN number. If connection is successful, you can view the remote and local files. Bluetooth ActiveSync To 1. 2. 3. setup your PC to accept Bluetooth ActiveSync: Go to MS Windows icon > settings > control panel. Select Bluetooth devices > COM ports. Add a COM port if needed. 4.
XM60 User Manual 5. 6. 7. Choose Bluetooth ActiveSync on your XM60 device. Pick the device that can accept Bluetooth ActiveSync. • You will see the serial port provided by the PC (make sure that your PC is not currently synching with another device. Tap OK and ActiveSync should start. To 1. 2. 3. set up Bluetooth LAN service: Go to file > Bluetooth LAN access.
XM60 User Manual To 1. 2. 3. 4. use Bluetooth COM service (create a BT virtual COM port): Choose COM service from file menu in the Bluetooth device manager. Pick the device for creating the virtual COM port. Select the COM number to map to. A success message appears, if your target device accepted the Bluetooth connection. To 1. 2. 3. check what service the scanned BT device supports: Choose the target device in the Bluetooth device manager. Click on property icon.
XM60 User Manual To check Bluetooth chip setting: 1. Go to tools > about. 2. The next screen will show the chip setting.
XM60 User Manual Janam Technologies LLC 8-8
XM60 User Manual 9 Beam Information You can beam any file or application between Janam connected handheld devices. Beaming distance to other connected devices may be different. Turn beaming on/off To turn beaming on or off: 1. Go to MS Windows icon > settings > control panel. 2. Double tap Irda icon. 3. Click on or off > OK.
XM60 User Manual Beam information To beam a file or application: 1. Navigate to Windows Explorer from the MS Windows icon in the command bar. 2. Select Windows Explorer. 3. Highlight or select the file you want to send. 4. From the top menu, select file > send to > beam files. 5. Aim the sending device IRDA window at the receiving XM60 IRDA window, about 6 inches apart. • You will have to acknowledge and accept the receipt of the file on the receiving device.
XM60 User Manual 10 Regulatory and Maintenance Regulatory and safety approvals The CE mark on the product indicates that the system has been tested to and conforms with the provisions noted within the 89/336/EEC Electromagnetic Compatibility Directive. For further information, please contact: Janam Technologies; 100 Crossways Park West, Suite 105, Woodbury, NY 11797. Janam Technologies shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.
XM60 User Manual XM Series RF Terminals with 802.11b and/or Bluetooth RF, regulatory and safety approvals Parameter Specification RF approvals U.S.A. FCC Part 15 Subpart C and Subpart B Canada RSS 210 Issue 6 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; and (2) this device must accept any interference received, including interference that may cause undesired operation.
XM60 User Manual RF, regulatory and safety approvals Parameter R&TTE Australia Specification EN 300 328 v1.6.1 (2004-11) EN 301 489-1 v1.6.1 (2005-09) EN 301 489-17 v1.2.1 (2002-08) EN 60950-1:2001+A11 EN 50371:2002 AS/NZS CISPR 22:2004 This product is marked with in accordance with the Class II product requirements specified in the R&TTE Directive, 1005/5/EC. The equipment is intended for use throughout the European Community. Its authorization for use in France is restricted as follows.
XM60 User Manual The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal. If you need more information on the collection, reuse and recycling of these systems, please contact your local region’s waste administration. You may also contact your supplier for more information on the environmental performances of this product.
