344 IBM System Storage DS6000 Series: Copy Services with IBM System z
Example 26-3 RQUERY GMLSTAT output when not addressing an LSS with an active session
RQUERY SNBR(01) VOLSER(XX2D00) ACTION(GMLSTAT)
RQUERY Output Volser(XX2D00) Action(GMLSTAT) Version(001)
SNbr GMLStat GoodCg Pct CrnBadCG TotBadCG LastGoodCGSCntlClock
-- ---------- -------- --- -------- -------- --------------------
01 NoConfig
LSS 2D00 has an active Global Mirror volume but it is not the Master LSS. Therefore,
RQUERY in Example 26-3 does not provide session summary information although both
LSSs reside in the very same primary storage disk subsystem. Note that the decision of
which LSS is the Master LSS, is made when the Global Mirror session is started.
Example 26-4 shows an example of the formatted output of the RQUERY command with the
ACTION(GMLSTAT) parameter specified.
Example 26-4 Session summary as the Master LSS reports
RQUERY SNBR(01) VOLSER(XX2C00) ACTION(GMLSTAT)
RQUERY Output Volser(XX2C00) Action(GMLSTAT) Version(001)
SNbr GMLStat GoodCg Pct CrnBadCG TotBadCG LastGoodCGSCntlClock
-- ---------- -------- --- -------- -------- --------------------
01 Running 0000D0C1 99 00000005 19 May 2005 19:08:00
.
Master: Serial SSID LSS CGInt CGDrn CrdInt
------------ ---- -- ----- ----- -----
000107527131 2C00 0C 0 600 5
.
BadCGrpFormation: When Serial SSID LSS Reason Activity
----- ------------ ---- --- ---------- ----------
Last 000107527131 2C00 0C CmdRej FCC StrtIncr
Prev 000107527131 2C00 0C CmdRej FCC StrtIncr
First 000107527131 2C00 0C CmdRej FCC StrtIncr
This is the active Global Mirror session as was shown in Figure 26-1 on page 342. During
these queries, a write workload was running on all three Global Mirror primary volumes.
26.2.4 Global Mirror session status for each LSS - GMPSTAT option
The ACTION(GMPSTAT) option returns Global Mirror session information with volume
counts, and out-of-sync tracks information, related to the addressed LSS.
Example 26-5 RQUERY session status for LCU 2C00, LSS 0C
RQUERY SNBR(01) VOLSER(XX2C00) ACTION(GMPSTAT)
RQUERY Output Volser(XX2C00) Action(GMPSTAT) Version(001)
SNbr LSS GMPStatus TotVol OOSVol OOSTrks
-- -- ---------- ------ ------ --------
01 0C CGInPrgrs 1 0 00000000
Example 26-5 shows the formatted output with the session status details for LCU 2C00.
