To Connect To Disconnect
1. Turn Everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to receptacles
4. Attach power cord(s) to outlet.
5. Turn device ON.
1. Turn Everything OFF.
2. First, remove power cord(s) from outlet.
3. Remove signal cables from receptacles.
4. Remove all cables from devices.
Note: In the UK, by law, the telephone cable
must be connected after the power cord.
Note: In the UK, the power cord must be
disconnected after the telephone cable.
96 Hardware Maintenance Manual A40 Type 6840 A40P Type 6841 A40i Type 2271: IBM NetVista Computer
