Intel X710 10 GbE SFP+ Network Adapter Family 11
Popular configurations
The following figure shows Intel 10 Gb Ethernet adapters that are installed in a supported rack server.
The servers are connected to a 10 Gb Ethernet network by using a pair of 10 Gb Ethernet switches.
Figure 3. Popular configuration
The parts used are listed in the following table.
Table 6. Components used with the Intel 10 GbE adapters (Figure 3)
Diagram
reference
Part number /
machine type
Description Quantity
Varies Supported server (See Table 5) 2
Varies Intel 10 Gb Ethernet Adapter (See Table 1) 2
Varies Supported 10 Gb SFP+ Transceivers or direct-attach cables (See
Tables 2 and 3)
4
Varies 10 Gb Ethernet Switch (See Table 6) 2
