ServeRAID-BR10il SAS/SATA Controller v2 for IBM System x 4
Supported servers
The ServeRAID-BR10il SAS/SATA Controller v2 is supported in the IBM System x servers listed in Table
2.
Table 2. Supported servers
Adapter
ServeRAID BR10il v2 N Y N Y N N N N N N N N N N N N N N
Notes:
For the x3200 M3, the adapter is only supported in models with hot-swap drive bays. The adapter is
z
installed in the dedicated PCI Express x4 slot without the use of the 2U or 3U bracket as shown in
Figure 2.
The x3250 M3 has the ServeRAID-BR10il v2 installed standard in all models. The adapter is installed
z
in the dedicated PCI Express slot without the use of the 2U or 3U bracket as shown in Figure 2.
Figure 2. Installing the ServeRAID-BR10il SAS/SATA Controller v2 in the x3200 M3 and x3250 M3
See IBM ServerProven for the latest information on the adapters supported by each System x server type:
http://ibm.com/servers/eserver/serverproven/compat/us/.
