Datasheet

QLogic QLE7340 Single-Port 40 Gbps QDR InfiniBand Host Channel Adapte

The parts used are listed in Table 3.

Table 3. Components used when connecting QLogic QLE7340 HCA to an InfiniBand network (Figure 2)

Diagram

reference

Part

number/machine

type

Description Quantity

Varies x3650 M2 or other supported server (See Table 2.) 1

59Y1888 QLogic QLE7340 HCA 1

Varies QLogic QDR InfiniBand QSFP Cable, copper or optical (See

Table 1.)

0449-020 QLogic 12200 (iDPx) 36-port QDR InfiniBand Switch Bundle 1

Supported operating systems

The QLogic QLE7340 HCA as part of an IBM Intelligent Cluster solution supports the following operating

systems:

SUSE Linux Enterprise Server (SLES) 10 and 11 (64-bit)



Red Hat Enterprise Linux 5 (64 bit)



Related publications

For more information refer to these documents:

Publications for the Cluster 1350:



http://www.ibm.com/support/docview.wss?uid=psg1MIGR-5080504

QLogic QLE7340 HCA product page:



http://www.qlogic.com/Products/HPCNetworking/InfiniBandAdapters/Pages/QLE7340.aspx
