Datasheet

QLogic QLE7340 Single-Port 40 Gbps QDR InfiniBand Host Channel Adapte
r
4
Supported servers
The QLogic QLE7340 HCA is supported in the IBM System x servers listed in Table 2 as part of the IBM
Intelligent Cluster portfolio.
Table 2. Supported servers in the IBM Intelligent Cluster portfolio
Feature
code
QLogic QLE7340 HCA 5763 Y Y Y Y Y Y Y Y N N N N N
Popular configurations
Figure 2 illustrates how the QLogic QLE7340 HCA can be used in configurations. In this example, we
connect all InfiniBand HCAs to a QLogic 12200 QDR InfiniBand switch.
Figure 2. x3650 M2 server with the QLogic QLE7340 HCA connected to an InfiniBand network
