PCM-9575 User’s Manual 30
3.3 Ethernet software configuration
The PCM-9575’s on-board Ethernet interface supports all major network
operating systems. To configure the medium type, to view the current
configuration, or to run diagnostics, do the following:
1. Power the PCM-9575 on. Make sure that the RSET8139.EXE file
is located in the working drive.
2. At the prompt, type RSET8139.EXE and press <Enter>. The Ether-
net configuration program will then be displayed.
3. This simple screen shows all the available options for the Ethernet
interface. Just highlight the option you wish to change by using the
Up and Down keys. To change a selected item, press <Enter>, and
a screen will appear with the available options. Highlight your
option and press <Enter>. Each highlighted option has a helpful
message guide displayed at the bottom of the screen for additional
information.
4. After you have made your selections and are sure this is the config-
uration you want, press ESC. A prompt will appear asking if you
want to save the configuration. Press Y if you want to save.
The Ethernet Setup Menu also offers three very useful diagnostic func-
tions. These are:
1. Run EEPROM Test.
2. Run Diagnostics on Board.
3. Run Diagnostics on Network.
Each option has its own display screen that shows the format and result of
any diagnostic tests undertaken.
23 B3 14 P5
24 B4 15 P6
25 B5 16 P7
26 ENAB 37 M/DE
27 GND 34 GND
28 VCC 5 +5 V
29 VCC 6 +5 V
30 GND 39 GND
Table 3.3: Connections to Toshiba LTM12C275A
