29 Chapter 3 Software Configuration
3.2.3 Connections to Toshiba LTM12C275A
(800 x 600 TFT color LCD)
CN1-25 OB5 CN 10-13 PD34
CN1-26 ENAB CN 11-37 M/DE
CN1-27 GND CN 11-34 GND
CN1-28 VDD CN 11-1 +5V
CN1-29 VDD CN 11-2 +5V
CN1-30 GND CN 11-8 GND
Table 3.3: Connections to Toshiba LTM12C275A
LTM12C275A PCM-9575 CN11
Pin Name Pin Name
1 GND 3 GND
2 NCLK 35 SHFCLK
3NC -NC
4NC -NC
5 GND 4 GND
6R0 27P18
7R1 28P19
8R2 29P20
9R3 30P21
10 R4 31 P22
11 R5 32 P23
12 GND 8 GND
13 G0 19 P10
14 G1 20 P11
15 G2 21 P12
16 G3 22 P13
17 G4 23 P14
18 G5 24 P15
19 GND 33 GND
20 B0 11 P2
21 B1 12 P3
22 B2 13 P4
Table 3.2: Connections to Toshiba
LTM15C151A
