PCA-6183 User’s Manual 138
C.24 CompactFlash Card Connector (CN26)
Table C.24: CompactFlash Card Connector (CN26)
Pin Signal Pin Signal
1GND 2D03
3D04 4D05
5D06 6D07
7*CS0 8A10
9 *ATA SEL 10 A09
11 A08 12 A07
13 +5 V 14 A06
15 A05 16 A04
17 A03 18 A02
19 A01 20 A00
21 D00 22 D01
23 D02 24 -IOCS16
25 *CD2 26 -CD1
27 D11 28 D12
29 D13 30 D14
31 D15 32 -CS1
33 *VS1 34 -IORD
35 *IOWR 36 -WE
37 INTRQ 38 +5 V
39 *CSEL 40 -VS2
41 *RESER 42 IORDY
43 *INPACK 44 -REG
45 *DASP 46 -PDIAG
47 D08 48 D09
49 D10 50 GND
* low active
