Owner's manual

8. External Dimensions
60
8.5 Flat Type L15SS
Effective
Stroke
150 250 350 450 550 650 750 850
L 390 490 590 690 790 890 990 1090
A 111 211 311 411 511 611 711 811
B 179.5 229.5 279.5 329.5 379.5 429.5 479.5 529.5
C 8 10 12 14 16 18 20 22
Weight (kg) 6.5 7.9 9.3 10.6 12.0 13.4 14.8 16.2
Effective
Stroke
950 1050 1150 1250 1350 1450 1550 1650
L 1190 1290 1390 1490 1590 1690 1790 1890
A 911 1011 1111 1211 1311 1411 1511 1611
B 579.5 629.5 679.5 729.5 779.5 829.5 879.5 929.5
C 24 26 28 30 32 34 36 38
Weight (kg) 17.5 18.9 20.3 21.7 23.1 24.4 25.8 27.2
115
9
3
17
9.8
17
C3
C3
7
5
20.2
10.2
7.3
4.5 2
4.3
18.5
14331
85(*1)
45
32 145
44.5
A59.5 80 80 59.5
145
115
B
175
L(st+240)
15
32.5 175
15
32.5
8
8
145
(max50)
22.522.5
2020 4545
ME
SE
45
ME
105
*The slider goes up the ME
in the home-return operation.
Pay attention to interference
to peripherals.
ME : Mechanical end
SE : Stroke end
Detail view of D
Detail: Base attachment
M4 T-slot
(D)
(*1) The cable track may bulge and
exceed the following dimentions slightly.
[Packaged T-nut]
Material: S10C or equiv.
Surface treatment: Unichrome plating
Weight: Appox. 14g/pc
Quantity: Refer to the row
“C” in the table
on the bottom
M5
Datum
surface
Cable
8-M5, depth 5 Heli-Coil insert
2-
φ
4H7, depth 6
HOME
4-
φ
4H7, depth 6
Widened slit for
easy T-nut insertion
Widened slit for
easy T-nut insertion
st
