Owner's manual

8. External Dimensions
59
8.4 Small Type H8HM
Effective
Stroke
130 230 330 430 530 630 730 830 930
L 806 906 1006 1106 1206 1306 1406 1506 1606
A 53 53 53 53 53 53 53 53 53
B 7 8 9 10 11 12 13 14 15
C 16 18 20 22 24 26 28 30 32
D 540 640 740 840 940 1040 1140 1240 1340
E 180 230 280 330 380 430 480 530 580
Weight (kg) 13.8 15.0 16.2 17.4 18.6 19.8 21.0 22.2 23.4
Effective
Stroke
1030 1130 1230
L 1706 1806 1906
A 53 53 53
B 16 17 18
C 34 36 38
D 1440 1540 1640
E 630 680 730
Weight (kg) 24.6 25.8 27.0
st
10
98160
st
80 D 80
50
A
75
(34)
(34)
L(st+676)
10
98 160
615
6
8528
80
75
16 52 16
2525 50
21
16.5
60
E E
23
72
86
100
97
31
35 80
5.5
2.7
1.8
5.8
3.3
8060
140
1
99
100
165
85
80
19
14
15
24
49
40
14
19
Detail view of F
Cable track for user (M type)Cable track for user (S type)
Cable track for user
section dimensions (M type)
Cable track for user
section dimensions (S type)
*The slider goes up the ME
in the home-return operation.
Pay attention to interference
to peripherals.
ME : Mechanical end
SE : Stroke end
M3 T-slot
(F)
Datum
surface
B×100
P
C-M5, depth 10
4-
φ
4H7, depth 5
HOME
HOME
4-M5, depth 10
2-
φ
4H7, depth 8
4-M3, depth 5
65±0.02
(Reamer pitch: ±0.02)
160 (Min. Distance between sliders)
(95)
ME
ME
