1. Specications Check
13
1.1.4 How to Read the Model Number
LSA
㧙
H8SS
㧙
I
㧙
200
㧙
50
㧙
T2
㧙
P
㧙
CT2
㧙
Note 1 Identification for IAI use only : It may be displayed for IAI use. It is not a code to show the
model type.
Series
<Type>
Small Type
H8SS:
width 80mm Single Slider
H8SM:
width 80mm Double Slider
H8HS:
width 80mm High-Thrust Single
Slider
H8HM:
width 80mm High-Thrust Double
Slider
Flat Type
L15SS:
width 145mm Single Slider
L15SM:
width 145mm Double Slider
<Encoder type>
I : Incremental
<Motor Type>
200: 200W
Identification for IAI use only
(Note1)
<Options>
None:
Cable Track
Attachment Orientation㧝
(Standard Equipment)
CT2 to 6㧦
Cable Track
Attachment Orientations 2 to 6
US1 to 6㧦
Cable Track for User S type
Attachment Orientations 1 to 6
UM1 to 6㧦
Cable Track for User M type
Attachment Orientations 1 to 6
<Cable length>
N : None
P : 1m
S : 3m
M : 5m
XƑƑ : Length Specification
<Controller>
T2 : SCON
: SSEL
: XSEL-P/Q
<Stroke>
[Refer to 1.2 “Specifications”]
