2. Installation
15
2. Installation
2.1 Name of Each Part
2.1.1 Slider Type (SA6C/SA7C)
2.1.2 Rod Type (RA6C/RA7C)
Connection port for teaching pendant or PC
(The arrow on the connector should face down.)
Non-motor end
Screw cover Coupling bolt
Right
Left
Motor end
Side cove
r
LED
Top
Bottom
Front bracket
Slider
Rear bracket
Motor bracket
Rear cover
Base
Motor cover
Cable
Connection port for teaching pendant or PC
(The arrow on the connector should face down.)
LED
Non-motor end
Motor end
Right
Left
Coupling bolt
Front bracket
Rear bracket
Motor bracket
Rear cover
Motor cover Cable
Rod
Frame
Rod end bracket
Top
Bottom
