1. Overview
9
1.6 Installation Environment and Noise Elimination
Pay due attention to the installation environment of the controller.
1.6.1 Installation Environment
The installation environment must satisfy the following conditions:
No. Use environment/condition
[1] Not exposed to direct sunlight.
[2] The actuator is not subject to irradiated heat from a large heat source, such as a heat treatment furnace.
[3]
Ambient temperature of 0 to 40qC.
[4] Humidity of 85% or less without condensation.
[5] Not exposed to corrosive or flammable gases.
[6] Normal environment for assembly and operation not subject to significant dust.
[7] Not exposed to oil mist or cutting fluid.
[8] Not subject to vibration exceeding 0.3 G.
[9] Not exposed to strong electromagnetic waves, ultraviolet light or radiation.
[10] Chemical resistance is not considered at all in the design of this product.
[11] The actuator and cables are not subject to electrical noise.
In general, the installation environment shall be such that the operator can work without wearing any protective gears.
1.6.2 Storage Environment
The storage environment shall conform to the installation environment, but special caution is required to prevent
condensation if the actuator is to be stored for a long period of time.
Unless otherwise specified, the actuator is shipped without any desiccating agent placed in the box. If the actuator is
to be stored in an environment subject to condensation, provide a non-condensing measure from outside the box or
directly inside the box.
The actuator is designed to withstand storage temperatures of up to 60qC for a short period of time. If the storage
period will extend beyond one month, however, keep the ambient temperature below 50qC.
