1. Overview
8
1.5 Transportation and Handling
1.5.1 Handling before Unpacking
Exercise due caution when transporting or handling the box containing the actuator, by not applying impact on the box
as a result of collision or dropping.
x If the box is heavy, one person should not carry it by himself.
x Place the box in a level surface.
x Do not step on the box.
x Do not place on the box any heavy object that may cause the box to deform or other object with a section where
loads will concentrate.
1.5.2 Handling after Unpacking
Once removed out of the box, hold the actuator by the frame if it is a rod type, or by the base if it is a slider type.
x When carrying the actuator, be careful not to allow it to collide with other objects. In particular, pay attention to the
front bracket, motor bracket and motor cover.
x Do not exert excessive force on each part of the actuator. In particular, pay attention to the motor cover and cables.
x When unpacking, exercise due caution not to let the actuator drop and sustain damage to its mechanism.
x If the actuator is damaged during the shipment or any of the items is found missing, please contact IAI’s Technical
Support immediately.
Supplement) Refer to 2.1, “Name of Each Part,” for the name of each part of the actuator.
