10. Maintenance and Inspection
149
10.8 Greasing the Rod Slide Surface
(1) Applicable grease
The following grease is applied to the rod slide surface prior to shipment:
Kyodo Yushi Multemp LRL3
Use lithium grease for maintenance.
Note: Never use fluorine grease. If fluorine grease is mixed with lithium grease, the grease function will drop
and it causes damage to the mechanism.
Caution:
In case the grease got into your eye, immediately go to see the doctor to get an appropriate care.
After finishing the grease supply work, wash your hands carefully with water and soap to rinse the
grease OFF.
