10. Maintenance and Inspection
146
10.5 Internal Cleaning (Slider Type)
x Wipe off dirt using a soft cloth, etc.
x Do not blow compressed air at high speed. Doing so may cause dust to enter the actuator through gaps.
x Do not use petroleum solvent, neutral detergent or alcohol.
Caution: Do not use cleaning oil, molybdenum grease or rustproof lubricant.
If a large amount of foreign object is contained in the grease, wipe off the dirty grease before
applying new grease.
10.6 Greasing the Guide (Slider Type)
(1) Applicable grease
IAI uses lithium grease No. 2.
The following grease is applied to the guides prior to shipment:
Idemitsu Kosan Daphne Eponex Grease No. 2
Equivalent grease products are available from other companies. For details, contact each manufacturer and ask for a
product equivalent to the aforementioned brand. Equivalence of the following products has been confirmed:
Showa Shell Sekiyu Albania Grease No. 2
ExxonMobil Mobilux 2
Caution:
In case the grease got into your eye, immediately go to see the doctor to get an appropriate care.
After finishing the grease supply work, wash your hands carefully with water and soap to rinse the
grease OFF.
