The difference IP camera brand has its own “Find” and “Advance setup” setup diagram and
setting process. For the detail information, please refer to the IP camera operation menu.
 HTTP port & RTSP port: The both port number must be matched the setting of IP camera which
you want to connect.
 Display streaming: You can select the “Dual streaming” or “None” mode; If you select the
“Dual streaming” mode, the live display video will show lower resolution
(320*240/640*480/720*480) for split video and higher resolution (same as recording resolution;
such as 1920*1080) for pop-up to single video on the screen. This Dual streaming mode for live
display can save a huge CPU loading when decoding the video streaming.
 Capture audio: You can record sound by microphone from audio input port of IP camera.
 Synchronization with the NVR time: Check to synchronize the time of IP camera with NVR.
 Condition (AWB): Choice the parameters to suit for the camera install location.
 Reboot: Click this icon will reboot the IP camera. .
 Setup: Click this icon for detail setting of IP camera (refer to I-View’s IP camera); you may not
need to I.E. Browser for the detail IP camera setting. Please refer the diagram as below:
