ida 812-1x MIO Operator’s Guide
Appendix A - FSL Functions
-48-
No. Name Syntax Parameters
59
Bar Code Type
Definition
%Y59,<n1>,<n2>,
<n3>,<n4>[,n5]%
n1
1-8 = Bar code def.
no.
n2
22-39 = Bar code
type
n3
1-255 = Height
n4
1-32 = Horizontal
expansion
n5
1-65535 = GFID No.
61
Setup for User
Strings
%Y61,<n1>,<n2>%
n1
0-7 = User String
No.
n2
00-FF = String
contents in HEX
62
Setup for IBM-
defined strings
(Tray select
strings)
%62,<n1>,<string>%
n1
120 = Tractor Tray 1
121 = Envelope feed
123 = Manual Cut-
sheet Feeder
125 = Tray 1
126 = Tray 2
127 = Tray 3
73
Select
Translate Table
%Y73,<n1>[,n2]%
n1 (Translate Table)
*1 = Roman-8
2 = IBM PC-8
3 = ECMA Latin 1
5 = US ASCII
6 = OCR A
7 = OCR B
8 = PC 850
n2 (Symbol Set)
*1 = Roman-8
2 = IBM PC-8
3 = ECMA Latin 1
5 = US ASCII
6 = OCR A
7 = OCR B
8 = PC 850
74
Printer Symbol
Set Definition
Strings
%Y74,<n1>,<n2>%
n1
1-8 = Symbol set no.
n2
00-FF = String
contents in HEX
