User Manual

12
TECHNICAL DATA
Voltage 40V Max
Bar length 12โ€
Chain speed 19.7 ft/s
Oil tank capacity 6.1 oz
Chain pitch 3/8โ€
Battery Capacity
ABP118T 2.5Ah
ABP118T7 2.0Ah
HT19-401-003-17 2.5Ah
Charger rating
HT19-401-003-14 120V~60Hz, 50W 20V
, 2.0A
HT19-401-003-13 120V~60Hz, 75W 20V
, 3.0A
ACG318W1U 120V~60Hz, 18W 20V
, 0.7A
Charging time 150mins for 2 batteries
Weight (chain & bar included) 7.7 lbs
The accessories of battery charger (HT19-401-003-13 /ACG318W1U) and battery pack (ABP118T7/
HT19-401-003-17 ) illustrated or described are not included in HT19-401-003-04 delivery.
Battery pack (ABP118T) 2
Charger ( HT19-401-003-14 ) 1
Blade protection cover 1
We recommend that you purchase your accessories from the same store that sold you the tool. Refer to the
accessory packaging for further details. Store personnel can assist you and o๎˜er advice.
ACCESSORIES
ASSEMBLY
WARNING! Do not install the battery pack before it has been completely assembled. Always wear
gloves when handling the bar and chain. These components are sharp and may contain burrs.
CHAIN AND GUIDE BAR ASSEMBLY
1. Unpack all parts carefully.
2. Remove the blade protection cover. (See Fig. A1)
3. Grip the chain tensioning outer rim and turning it anti-clockwise to loosen the chain. (See Fig. A2)
4. Hold and depress the cover tightening stick, turning it anti-clockwise to remove the chain cover. (See Fig. A3)
5. Place the chain saw on a solid, level surface.
6. Slide the chain in the slot around the guide bar. Ensure the chain is in correct running direction by referring
to the chain direction symbol found on the saw body. Ensure the bar tensioning plate is facing outward. (See
Fig. A4)
NOTE: Hold the bar vertically and slide the chain from the top of the bar. It will help you to smoothly assemble
