Instruction Manual

HDA 5500 for HLB 1000 and CS 1000
- 13 -
Menu point Setting Setting range Default setting
Allocation of switching output 2 (S.S.2)
Similar to switching output 1 (see above), and likewise for:
• Switching mode (S.M.2)
• Switching direction (S.d.2)
• Switch-on delay (T.on.2)
• Switch-off delay (T.oF.2)
Channel 1
Channel 2
Channel 3
Channel 4
SP
Win
on
oFF
0..99.99 s
0..99.99 s
Channel 1
SP
on
0
0
Allocation of switching output 3 (S.S.3)
Similar to switching output 1 (see above), and likewise for:
• Switching mode (S.M.3)
• Switching direction (S.d.3)
• Switch-on delay (T.on.3)
• Switch-off delay (T.oF.3)
Channel 1
Channel 2
Channel 3
Channel 4
SP
Win
on
oFF
0..99.99 s
0..99.99 s
Channel 1
SP
on
0
0
Allocation of switching output 4 (S.S.4)
Similar to switching output 1 (see above), and likewise for:
• Switching mode (S.M.4)
• Switching direction (S.d.4)
• Switch-on delay (T.on.4)
• Switch-off delay (T.oF.4)
Channel 1
Channel 2
Channel 3
Channel 4
SP
Win
on
oFF
0..99.99 s
0..99.99 s
Channel 1
SP
on
0
0
