Replacement Part List

118791_1113 7-3
Seat, Standard
NOTES:
1. Do not torque; the seat pan must pivot freely.
2. Torque to 7 ft-lbs.
INDEX NO. PART NO. QTY. DESCRIPTION
1 792226 1 STANDARD SEAT
2 551897 1 SEAT PAN (WITH DECAL)
3 604307 1 PUSH BUTTON MOUNT
4 086660 2 NT .375-16 NL G5
5 000331 1 WIRE TIE
6 768523 4 FW .343 X .687 X .051/.080H
7 079186 4 CS .312-18 X 1.25 HX G5
8 029629 3 CS .375-16 X .75 HX FLK
9 793851 3 COMPRESSION SPRING 1.25 X 4.00 X .188
10 016899 3 NT .375-16 HX FLK ZNYC
11 036244 2 CS .375-16 X 1.00 HX G5
12 601815 1 BATTERY WARNINGS DECAL
