Replacement Part List

118791_1113 6-13
54" Deck
NOTES:
1. Torque to 118 ft-lbs.
INDEX NO. PART NO. QTY. DESCRIPTION
1 604722 1 RS PULLEY COVER
2 604324 4 CS .250-20 X .75 HX FLG
3 604817 1 BELT, B-SECTION
4 604723 1 LS PULLEY COVER
5 604609 1 DISCHARGE CHUTE
6 604346 1 DISCHARGE CHUTE PIN
7 604331 1 CHUTE SPRING
8 086660 1 NT .375-16 NL G5
9 604658 2 PULLER PIN
10 117877 1 RS PULLER
11 117878 1 LS PULLER
12 781567 3 NT .500-13 NL G5
13 767962 3 FW .531 X 1.063 X .090 SAE
14 788166 3 PLASTIC WHEEL ASSEMBLY
15 601124 3 BLADE, 18.50"-L-F-CW
601012 3 BLADE, F18.50"-L-F-CW
797696 3 BLADE, F18.50"-H-F-CW
797704 3 BLADE, 18.50"-MUL-F-CW
797712 3 BLADE, 18.50"-GAT-F-CW
16 782474 3 CW .631 X 2.25 X .187 PNT
17 781872 3 CS .625-11 X 1.25 HX G5 Z
18 017301 2 HP .125 X 2.375 ZN
19 781708 1 CS .500-13 X 4.25 HX G5
20 767962 2 FW .531 X 1.063 X .090 SAE
21 031997 1 PLASTIC WHEEL
22 053199 1 NT .500-13 HX JAM ZNYC
